ILVE brings the ultimate cooking experience to your kitchen with Panoramagic's modern touch to your kitchen combined with traditional Italian style and technology. This 36" induction range comes featured with Total Black Brass Non-Stick Nanotechnological Treatment, Easy Clean Enamel Oven Interior, and 4.3" Touch Screen Oven Control.
Features
Panoramagic
A tradition of the contemporary kitchen that withstands the test of time.
It was during the fantastic 1960s that ILVE launched Panoramic: the free-standing model that revolutionized the panorama of the domestic kitchen. Today, this tradition of Italian style and technology continues to take charge and fascinate: in an updated form and with a full range of solutions to fit into any interior design.
Unique design that combines the technical featuresof professional kitchens with the Italian culture of design,Panoramagic range cookers come in three models,all with a 4.3-inch touch screen: 48 inches with double ovenand precise temperature control, 36 inches with 6 burnersor with induction hob with 6 zones. The gas hobs use dualburners up to btu 20000 as standard and a highly professional
nanotechnological treatment to achieve a non-stick surface witha total black finish.
- Total Black brass flame spreader with non-stick nanotechnological treatment
- Dual gas burners with power up to btu 20000 as standard
- Highly specialized cooktops
- LED backlit knobs
- Hob with cast iron pan supports
- Display 4.3" full touch
- Door with softclosing system
- Precise electronic temperature control
- Warming drawer with soft-closing system
- Steam discharge
- Cooking probe
- Cold door with triple removable glass
Total Black brass flame spreader with nonstick nanotechnological treatment
The noble technical characteristics of brass are enriched with a nanotechnological coating that assures easy cleaning, with an elegant Total Black finish.
Hob with cast iron pan supports
The indestructible cast iron pan supports provide a functional and safe support for the pots.
Quick start
The quick oven preheating function allows it to reach the desired temperature in a short time and you can then choose the best-suited cooking mode for the dish. It also works as rapid defrosting when a low temperature is set (85°F - 105°F).
Cold door with triple removable glass
Safe with children, perfectly insulated thanks to the three layers, and easy to clean.
Tangential cooling ventilation and high-density insulation
Prevents the furniture next to the oven and the kitchen from overheating.
Precise electronic temperature control
The electronic control ensures that the temperature of the oven remains constant throughout, without fluctuating, as is the case in conventional ovens. It can be set with precision starting from 85°F, for perfect proofing, up to 575°F, for roasting.
Cooking probe
An essential accessory to check the temperature at the core, for example in meat cuts.
Steam discharge
Thanks to this system, the vapors are removed from inside the cavity, allowing you to choose a drier or more moist cooking. This way, you can achieve a crispy baked dish or a soft and juicy roast.
Temperature from 85° to 575° F
From proofing to cooking, roasting to low temperature, ILVE ovens allow you to prepare complex and sophisticated recipes very easily, with perfect results.
Folding grill coil for complete cleaning
Thanks to the articulated support, the electric heating element of the grill can be lowered to clean the top part of the cavity more easily.
Door with soft closing system
The door hinges are fitted with a shock absorber that makes the closure more gradual and noiseless.
Easy clean enamel
The grease does not stick to the surface and can therefore be cleaned more easily.
Warming drawer
With soft-closing system
4.3€� full touch display
Thanks to TFT technology, the display assures superior readability, displaying every function with clear and immediate graphics.
Details
APPEARANCE
Style: Freestanding
Cooktop: Smoothtop
Drawer: Warming
Viewing Window: Yes
Fuel Type: Electric
Digital Clock: Yes
DIMENSIONS
Exterior Width: 36"
Width: 35.875"
Height: 35.75"
Depth: 29.25"
OVEN FEATURES
Total Capacity: 3.5 cu. ft.
Dual Door: No
Broiler: Yes
Convection: Yes
Digital Temperature Display: Yes
Oven Control Type: Digital
Double Oven: No
Timer: Yes
Temperature Probe: Yes
Interior Oven Light: Yes
COOKTOP FEATURES
Burners / Elements: 6
Elements: 6
Cooktop Control Type: Knobs
Downdraft Ventilation: No
Hot Surface Indicator Light: Yes
Griddle: No
Grill: No
Backlit Knobs: Yes
French Top: No
Simmer Burner:Yes
Highest Element Output: 20000 BTU
BURNER OUTPUT
Front Left Output: 20000
Back Left Output: 10500
Back Right Output: 10500
Front Right Output: 16500
Middle Back Output: 10500
Middle Front Output: 7000
ELECTRICAL SPECIFICATIONS
Volts: 240 Volts
Amps: 30 Amps
CERTIFICATION
ADA Compliant: No
